Saddle Fusion Machine MAX315
- Model
- MAX315
Item specifics
- Certificate
- CE, ISO9001
- Packing Material
- Plywood Pallet
- MOQ
- 1set
Review
Description
Saddle Fusion Machine MAX315
MAX315 is designed to fabricate an reducing tee with various pipe specifications.
This largely fills a vacancy in the coordination of different pipe diameters, which should be applied to special projects.
|
Product Details
|
|||
|
WELDING TYPE
|
SADDLE T TYPE
|
APPLIED MATERIAL
|
PE/PP/PVDF
|
APPLICABLE ENVIRONMENT TEMPERATURE | -10 ~ 45 | VOLTAGE | AC 380V, 50/60HZ |
|
MAX315 Standard Configuration Table (Unit: mm)
|
||||||||||||
BRANCH \MAIN | 90 | 110 | 125 | 140 | 160 | 180 | 200 | 225 | 250 | 280 | 315 | Driller |
|
32
|
√
|
√ | √ | √ | √ |
-
|
-
|
- | - | - | - | √ |
40 | √ | √ | √ | √ | √ | - | - | - | - | - | - | √ |
50 | - | √ | √ | √ | √ | √ | √ | - | - | - | - | √ |
63 | - | - | - | √ | √ | √ | √ | √ | √ | - | - | √ |
75 | - | - | - | - | √ | √ | √ | √ | √ | √ | - | √ |
90 | - | - | - | - | - | √ | √ | √ | √ | √ | √ | √ |
110 | - | - | - | - | - | - | - | √ | √ | √ | √ | √ |
125 | - | - | - | - | - | - | - | - | √ | √ | √ | √ |
140 | - | - | - | - | - | - | - | - | - | √ | √ | √ |
|
160
|
-
|
- | - | - | - |
-
|
-
|
- | - | - | √ | √ |
Standard Composition
- Suitable for fabricating HDPE-reducing tee in a workshop. The integrated function of welding and taping enables to completion of the whole fabricating process.
- Sturdy machine bed.
- Slide with highly precise linear guides.
- Hydraulic jaws for locking main pipe & manual jaw for locking branch pipe.
- Manual movement of the heating plate that can host male/female sockets with a heating plate detaching device.
- Manual operation
- Reduced tee driller
- Convex and concave die (on request)
