Trailer Fusion Machine ARMOR 355i 110MM-355MM (4" IPS - 14'' IPS)
- Model
- ARMOR 355i
Item specifics
- Certificate
- CE, ISO9001
- Packing Material
- Plywood Box
- MOQ
- 1set
- Working Range in MM
- 110mm - 355mm
- Working Range in Inch
- 4 - 14Inch
- Working Pressure Range
- 0 - 110Bar
- Welding Standard Applied
- ASTM F2620-20, ISO 21307 SHP
Review
Description
Trailer Butt Fusion Machine ARMOR 355i 110MM-355MM (4" IPS - 14'' IPS)
Riyang ARMOR 355i is a high-performance fusion welding machine with trailer mobility, designed to excel on construction sites.
It boasts a welding range from 110mm to 355mm or 4" to 14", adhering to ISO21307 and ASTM F2620 high-force standards.
With a fully automated system featuring SIEMENS PLC technology, ARMOR 355i ensures precision and reliability.
Crafted from premium aluminum components, this machine guarantees strength and accuracy for all your welding needs.
|
Product Details
|
|
|
Models
|
|
902306355, ARMOR 355i | Automatic, High Force, 220/380V, 50/60Hz, 3 Phase |
902307355, ARMOR 355 | Manual, High Force, 220/380V, 50/60Hz, 3 Phase |
|
Capacity
|
|
|
Welding Range
|
110mm-355mm, 4"IPS-14"IPS
|
Inserts Type | Quick Fit |
Power | |
Heater | 4KW |
Trimmer | Hydraulic |
Electric Motor | 4KW |
Hydraulic | |
System Pressure | 110 Bar (1595 PSI) Max. |
Hydraulic Reservoir Capacity | 23 Liters (6 Gallons) |
Weight | |
Machine | 600 Kg (1320 lbs.), excluding inserts |
Shipping | 750 Kg (1650 lbs.), excluding inserts |
Chassis | |
Frame | Welded steel tube construction |
Front Axle | Linkage |
Tires | High-flotation inflatable tires |
Transportation | Pulled via towing ring |
Machine Carriage | Removable |
Dimension | |
Machine | 2000mm x 1340mm x 1640mm 79" x 53" x 65" |
Machine Carriage | 1080mm x 915mm x 707mm 43" x 36" x 28" |
Shipping | 2230mm x 1520mm x 1640mm 88" x 60" x 65" |
Optional Configuration | |
Inserts | √ |
Stub End Device | √ |
Mobile Support Roller | √ |
Data Logger | Compatible with manual version |
•The dual-axis structural frame ensures strength
and even distribution of welding force
•On-board heating plate with protection
frame and insulated shield
•On-board high-capacity trimmer driven by
hydraulic power
•Removable machine chassis for in-ditch use
• Dragging bar designed to weld between the
3rd and 4th clamp
•Removable trimmer for welding short spigot
• Single-size insert with quick
install/release system
• Strong jaws and inserts keep the pipe from
slipping during fusion
•Hydraulic pipe lift used to loading and
unload pipe
•Data logger (PEWELDBANK) is compatible
(manual version)
• Removable control panel with
data-logging, memory of up to 30000 welding reports; USB port for welding data
download/firmware upgrade
• Easy welding procedure achieved by
operator just pressing the button
