Saddle Fusion Machine MAX1200i
- Model
- MAX1200i
Item specifics
- Certificate
- CE, ISO9001
- Packing Material
- Plywood Pallet
- MOQ
- 1set
- Model
- MAX630i
- Item Code
- 702309122
- Welding Range / Main Pipe
- φ630-1200mm, φ24-48" IPS
- Welding Range / Outlet Pipe
- φ315-630mm, φ12-24" IPS
- Operation Mode
- Automatic
Review
Description
Saddle Fusion Machine MAX1200i
MAX1200i is designed to fabricate reducing tee with various pipe specifications.
This largely fills a vacancy in the coordination of different pipe diameters, which should be applied to special projects.
|
Product Details
|
|||
|
WELDING TYPE
|
SADDLE T TYPE
|
APPLIED MATERIAL
|
PE/PP/PVDF
|
APPLICABLE ENVIRONMENT TEMPERATURE | -10℃~ 45℃ | VOLTAGE | AC 380V, 50/60HZ |
|
MAX1200i Standard Configuration Table (Unit: mm)
|
|||||||
BRANCH \MAIN | 560 | 630 | 710 | 800 | 900 | 1000 | 1200 |
|
160
|
√
|
- | - | - | - |
-
|
-
|
200 | √ | √ | √ | - | - | - | - |
225 | √ | √ | √ | √ | - | - | - |
250 | √ | √ | √ | √ | √ | - | - |
280 | √ | √ | √ | √ | √ | √ | - |
315 | - | √ | √ | √ | √ | √ | √ |
355 | - | - | √ | √ | √ | √ | √ |
400 | - | - | - | √ | √ | √ | √ |
450 | - | - | - | - | √ | √ | √ |
500 | - | - | - | - | - | √ | √ |
560 | - | - | - | - | - | - | √ |
630 | - | - | - | - | - | - | √ |
Featured by
- Suitable for fabricating an HDPE reducing tee in a workshop. The integrated function of welding and taping enables the completion of the whole fabricating process.
- A Teflon-coated heating plate.
- Separate two-channel timer records times in soaking and cooling phases.
- Digital high-accuracy pressure meter indicates exact readings.
- Linear guide ways are equipped with a heating plate and a dragging plate.
