Geomembrane Hot Wedge Welder RYG700
Geomembrane Hot Wedge Welder RYG700
Geomembrane Hot Wedge Welder RYG700
Geomembrane Hot Wedge Welder RYG700
Geomembrane Hot Wedge Welder RYG700
Geomembrane Hot Wedge Welder RYG700
Model
RYG700

Item specifics

Certificate
CE, ISO9001
Packing Material
Aluminum Box
MOQ
1set

Review

Description

Geomembrane Hot Air Welder RYG700
Geomembrane Hot Wedge Welder adopts an advanced hot air heating system. With small, light, and high speed, it perfects the welding quality even if corrosive materials and bad working environment.

This machine is specially designed for tunnels, subway, water conservancy, aquaculture, biogas plants, landfills, chemical mining, sewage treatment, roof constructions, and other waterproofing projects.
Product Details
VOLTAGE
220V, 50/60HZ
POWER
3000W
WELDING SPEED
0.5 - 4.5M/MIN ADJUSTABLE
HEATING TEMPERATURE
20℃ - 620℃
 ADJUSTABLE
MATERIAL THICKNESS WELDED
0.5MM - 2.0MM (SINGLE LAYER)
OVERLAP WIDTH
16CM
SEAM WIDTH
15MM*2, INTERIOR CAVITY 15MM
SEAM STRENGTH
≥ 85% MATERIALS
NET WEIGHT
7.5KGS
PACKING MATERIAL
ALUMINUM BOX
Pipe Fusion Machine
Butt Welding Machine
Control System
Advanced intelligent digital control system with temperature and speed readed on LCD screen.
Butt Fusion Machine
Pressure Adjustment System
Adanced "T" jib design and pressure regulation structure.
Hdpe Pipe Welding Machine
Pressure Rollers
Special stainless steel pressure rollers with strong pressure force.
Hdpe Welding Equipment
Hot Air Heating System
Advanced hot air heating system perfects the welding quality even if corrosive materials and bad working environment.
Hdpe Fusion Machine
    - Railway/ highway subway tunnel waterproof construction;

    - Water conservancy projects, man-made landscape;

    - Riverbank, aquaculture farm;

    - Refuse landfill, sewage treatment;

    - Chemical, mining industry;

    - Construction waterproofing projects.
