Model
V160

Item specifics

Certificate
CE, ISO9001
Packing Material
Plywood Box
MOQ
1set
Working Range in mm
50mm - 160mm
Working Range in Inch
2" - 6" IPS
Working Pressure Range
0 - 80Bar
HDPE Welding Standard Applied
ISO21307, DVS2207/1, ASTM F2620 etc.

Review

Description

Hydraulic Butt Fusion Machine V160 50MM-160MM (2" IPS -6" IPS)


The V160 Butt Fusion Welding Machine from RIYANG is designed to meet the demanding requirements of various applications, ensuring precise and reliable fusion welding. Key application areas include:

● Water Infrastructure: Ideal for joining thermoplastic pipes in water supply networks, guaranteeing secure and leak-free connections.
● Gas Distribution Systems: A reliable solution for welding pipes in gas distribution systems, ensuring the integrity of gas infrastructure.
● Industrial Pipelines: Suited for a range of industrial applications utilizing thermoplastic pipes, providing durable fusion joints.
● Mining Industry: The V160 excels in the mining sector, delivering efficient fusion welding for pipelines critical to mining operations, ensuring dependable and durable connections for water, chemicals, or other resources.
Product Details
WELDING RANGE O.D.
50 - 160 MM
WELDING RANGE INCH
2" - 6" IPS
POWER SUPPLY
220V±10%, 50/60HZ
TEMPERATURE RANGE
MAX. 280 ºC
HEATER POWER
1.0 KW
PACKING DIMENSION
820*400*380 MM
TRIMMER POWER
0.75 KW
440*400*520 MM
PUMP POWER
1.1 KW
650*340*380 MM
WORKING PRESSURE RANGE
0 - 80 BAR
GROSS WEIGHT
133 KGS
Machine Chassis

● The integral frame features a quick and detachable structure, facilitating rapid maintenance and repair.
● The compact and robust frame structure resists deformation and oil leakage when handling thick pipes with extreme parameters.
● Key hydraulic components are sourced from industry-leading suppliers, primarily from Germany, Italy, and Japan.


Heating Plate & Trimmer

● Utilizes Teflon material from a leading industry brand, reducing adhesion between the heating plate and melted plastic for an extended service life.
● Each side of the heating plate maintains a temperature difference of less than 3°C.
● The stainless steel construction of the junction box ensures corrosion resistance.
● Employs a powerful electric drill for efficient pipe milling with a long service life.
● Ergonomic operation handle designed in accordance with ergonomic principles.



Power Station

● Robust hydraulic power with a maximum system pressure of up to 80 bar.
● Pressure valves employ cartridge valves for quick maintenance and repair.
● Precise temperature control reduces the discrepancy between actual and displayed temperature values, ensuring welding quality.
● The integral frame features a quick and detachable structure for efficient maintenance and repair.
● Compact and robust frame structure resists deformation under external pressure.

RIYANG data logger PEWELDBANK
Data Logger PEWELDBANK
stub end holder Riyang
Aluminum Stub End Holder
RIYANG pipe roller support
Roller Support
Inserts
